Model:China ATV250CC08

Approve mode:EEC EPA DOT
Product Description:
(1)Engine;single cylinder, water-cooling, four-stroke
(2)Ignition mode: CDI
(3)Compression proportion: 10.5:1
(4)Start mode: electric
(5)Meter Central Headlight with Speedometer
(6)Fuel tank capacity: 11L
(7)Transmission mode: shaft drive
(8)Power: 10.5kW/7,500rpm
(9)Max. torque 15Nm/5,500rpm
(10)Min. ground clearance: 155mm
(11)Max. speed ≥55km/h
(12)Power source: 12V, 14Ah
(13)Transmission:4 gears with reverse gear, manual clutch
(14)Cylinder size: 63.5 x 62.2mm
(15)Engine oil: 1.3L
(16)Gear oil: 0.25L
(17)Lubrication: press splash
(18)Displacement: 250/300/350CC
(19)Parking trig: mechanical lock
(20)Front wheels: 23 x 7 - 10
(21)Rear wheels: 22 x 10 - 10
(22)Break type (F/R): disc/disc
(23)Front hanging: single arm-swing
(24)Rear hanging: integral
(25)Product dimensions : 1,850 x 1,030 x 1,130mm
(26)Carton dimensions: 1,970 x 1,110 x 880mm
(27)Wheelbase: 1,160mm
(28)Height of seats: 820mm
(29)Dry weight: 230kg
(30)Load capacity: 165kg
(31)Climbing degree: ≥25°
(32)Min. turning radius: 2,900mm
